SKU
16-55708-1
Alt #:
64-55708
Model T Ford Electrical Wiring Diagram Fold-Out
0
Reviews
Add Your Review
$9.99
Each
Fitment
Model T, 1919 thru 1925
View More
Product Details
This is a very detailed, large blueprint type double page foldout drawing that shows the exact wiring connections.
Availability:
In Stock - 3-5 Day Delivery
This is a very detailed, large blueprint type double page foldout drawing that shows the exact wiring connections.
| Base Part Number | 55708 |
|---|---|
| Alt. # | 64-55708 |
| MAC's Legacy # | T5039 |
| Brand | N/A |
| Make / Model | Series | Body | Notes | Year |
|---|---|---|---|---|
| Make / Model Ford Model T | Series | Body | Notes | Year 1919, 1920, 1921, 1922, 1923, 1924, 1925 |
